Industrial biomass steam boilers for plants with sustained process loads. Review 20, 25 and 35 t/h project references, then specify the output, pressure and fuel available at your site.
MODEL & OPERATING PARAMETERS
Biomass steam boilers
Our biomass steam boiler range covers 10–130 t/h with design pressures of 1.25–5.3 MPa. The design is selected for the required capacity, fuel and operating conditions. The individual project rows below retain their documented steam parameters.
| Model / configuration | Output | Pressure | Basis |
|---|---|---|---|
| Biomass steam boiler family | 10–130 t/h | 1.25–5.3 MPa (design) | Current product range |
| SHW25-1.25/230-T | 25 t/h | 1.25 MPa | Pakistan delivery record; 230 °C steam |
| Vertical biomass boiler, Heze | 40 t/h | 2.5 MPa | Published operating project |
| SHW20-2.5/400-T | 20 t/h | See model-specific proposal | Indonesia palm-waste project |
Product data & references: Biomass catalogue · 25 t/h model record · 40 t/h pressure reference · Indonesia model reference
QUICK COMPARISON
Biomass boilers at a glance
| Heating need | Useful sizing information |
|---|---|
| Process steam | Output in t/h; working pressure and steam temperature. |
| Hot water | Heat duty in kW or MW; supply/return temperatures and system pressure. |
| Thermal oil | Heat duty in kW or MW; oil type and supply/return temperatures. |
For pellets, wood chips, sawdust or agricultural residues, share composition, moisture, particle size and ash content. Suitability, fuel feeding and combustion design are reviewed for the actual fuel.
THERMAL OIL HEATER SHIPMENT
Watch the 10 million kcal/h biomass thermal oil heater shipment to PakistanBIOMASS PROJECT VIDEOS
Watch the 25 t/h biomass steam boiler in PakistanWatch biomass fuel feeding and boiler operation
Fuel-led boiler selection
Bagasse, rice husk, wood chips, sawdust and palm residues have different combustion and handling characteristics. We review the fuel analysis, supply consistency and plant load before proposing the furnace, grate and auxiliaries.
Designed around continuous production
Discuss normal and peak steam demand, load variation, maintenance access and critical spares. The rated output and operating conditions are established in the project-specific technical proposal.
What a 10 ton steam boiler enquiry should include
Start with the required steam output and pressure, production schedule, fuel type and project location. If the final demand is not known, choose “Help define the application” in the consultation form and share your production capacity.
PLAN YOUR BOILER PROJECT
What we need to specify your system
- Available biomass, fuel size, moisture and ash content
- Steam demand and pressure, or thermal oil operating temperature
- Fuel supply consistency, operating hours and project location
PLANNING A PROJECT IN PAKISTAN?
Explore biomass boilers, thermal oil heating and Pakistan project referencesPublished steam boiler references
| Project | Steam output | Identified fuel |
|---|---|---|
| Indonesia | 20 t/h | Palm-processing waste |
| Karachi, Pakistan | 25 t/h | Chicken manure, cow dung and rice husks |
| Myanmar | 35 t/h | Biomass pellets |
Product configuration & technical illustrations
The source diagrams below show product configurations. Confirm the final specification with our engineering team.
BIOMASS FUEL SELECTION
Rice straw first. A clear fuel specification.
Prioritise rice straw, cow manure, rice husk and wood chips. Confirm the acceptable heating-value, moisture and ash ranges from actual fuel analysis before agreeing the boiler design.
Additional wood-fuel illustration
Rice straw
Review preparation, feeding and ash behaviour. Share net heating value, moisture, ash and seasonal variation.
Cow manure
Report moisture, ash, impurities, bedding material and the proposed blend.
Rice husk
Provide analysis of the actual husk supply and describe storage and feeding conditions.
Wood chips
Specify chip size, moisture, ash and the consistency of supply.
No laboratory report yet?
Send the information you have and mark missing values as unknown. Fuel photos help describe the material but do not replace analysis. When providing a report, keep its units and test basis; do not enter zero for an unknown value.
See the published 18 t/h pellet case in Yinan, China ↗
This pellet reference does not confirm suitability for your wood chips or sawdust. Final configuration depends on the actual fuel and process requirements.
BEFORE YOU REQUEST A QUOTE
From process requirements to an agreed scope.
- Describe your process. Share the heating application, output, fuel and project country. Add operating hours, site conditions and the details you already know.
- Review the configuration. Discuss the boiler, fuel feeding, ash removal, water treatment, flue-gas cleaning and controls required by your project.
- Confirm the offer. Agree included equipment, exclusions, documentation, delivery, installation responsibilities, commissioning and support arrangements before ordering.
Can we use our available biomass fuel?
Send its origin, composition, moisture, particle size, ash content and photos. A reference using one fuel does not confirm suitability for another fuel or operating condition.
What determines the price and delivery schedule?
Capacity, working conditions, fuel properties, agreed auxiliaries, documentation and destination affect the offer. Price, production schedule, shipping terms and spare parts are confirmed for the agreed scope.
What documents and installation support are included?
Tell us your local requirements. The proposal should state the applicable documentation and the responsibilities for transport, installation and commissioning. See the supplied Chinese manufacturing licences and their validity dates; project-specific conformity requirements must be confirmed separately.
View manufacturing licences ↗Keep the key details for your team.
Company background, product selection, verified references and an enquiry checklist in one short guide.
Download buyer guide · English PDF ↓
