The boiler design for the single-layer layout,with a compact structure,easy operation of the installation operation,boiler room lowcost,can save more than 40%of boiler room investment.
FEATURES
1,the boiler design for the single-layer layout,with a compact structure,easy operation of the installation operation,boiler room lowcost,can save more than 40%of boiler room investment.
2,the boiler has a natural circulation convection heating surface,outlet foot,the accident rate is low,safe and reliable operation.
3,the furnace with a whirlwind burning chamber,reducing the dust content of flue gas,while the hot carbon particles further combustion,improve the boiler thermal efficiency,Reduce the smoke blackness,flue gas concentration to meet a class of environmentally friendly areas,and because part of the flue gas in a large diameter of the particles in the cyclone The incineration chamber is separated so that the dust concentration of the flue gas entering the convective tube bundle is reduced,the wear on the convective heating surface is reduced and the boiler Of the service life.
4,grate with scale and side grate and other patented technology,greatly improving the reliability of the boiler operation.
5,sealed wind chamber,double into the wind,grate ventilation device using mechanical processing of the cone seal structure,to improve the sensitivity of the furnace ventilation,is the country Protect patented technology.
6,according to user requirements supporting the implementation of the national stratified combustion devices and other energy-saving equipment.
